MODEL | MOYUPAC-01 | MOYUPAC-02 | MOYUPAC-03 | MOYUPAC-04 | MOYUPAC-05 |
POWER SOURCE | 220-240V 50HZ | 220-240V 50HZ | 220-240V 50HZ | 220-240V 50HZ | 220-240V 50HZ |
COOLING CAPACITY(W) | 2000 | 2600 | 3500 | 4000 | 4600 |
HEATING CAPACITY(W) | 2000 | 2600 | 3500 | 4000 | 4600 |
COOLING POWER CONSUMPTION(W) | 900 | 1100 | 1480 | 1700 | 2000 |
HEATING POWER CONSUMPTION(W) | 700 | 950 | 1300 | 1580 | 1700 |
MOISTURE REMOVAL(L/Day) | 30 | 50 | 60 | 70 | 80 |
NOISE LEVEL(dB) sound power | 51 | 52 | 52 | 53 | 55 |
NOISE LEVEL(dB) sound pressure | 65 | 65 | 65 | 65 | 65 |
AIR VOLUME(M3/H) | 360 | 400 | 450 | 450 | 520 |
REFRIGERANT | R410A | R410A | R410A | R410A | R410A |
UNIT DIMENSION(W*D*H mm) | 526*300*624 | 480*300*630 | 550*300*760 | 550*300*760 | 550*300*760 |
PACKING DIMENSION(W*D*Hmm) | 560*330*660 | 510*330*660 | 580*330*815 | 580*330*815 | 580*330*815 |
NET WEIGHT(Kg) | 24 | 25 | 29.5 | 30.5 | 32 |
GROSS WEIGHT(Kg) | 26 | 27 | 31.5 | 32.5 | 34 |
APPLICANT AREA(M2) | 8~12 | 12~16 | 21-29 | 30-40 | 40-45 |
ENERGY LABEL | Class A | Class A | Class A | Class A | Class B |
LOADING QUANTITIES (20'FT/40'GP/40'HQ) | 210/440/588pcs | 210/440/588pcs | 210/440/588pcs | 140/288/430pcs | 140/288/430pcs |
